Eagle PCB Design Software
Summary
1. Introduction
Eagle is a proprietary Computer Assisted Drawing (CAD) software for designing Printed Circuit Boards (PCBs) from Schematics to Gerber Files. This is the software that have primarily been used to design the MBHP PCB modules
You can find the official website here : http://www.cadsoftusa.com/
2. Installation
First, download the correct installer for your operating system at
http://www.cadsoftusa.com/download-eagle/
Follow the instructions to get the program installed
3. Getting Started
A serie of official Getting Started videos to be found here:
http://www.cadsoftusa.com/eagle-pcb-design-software/guided-tour/#c760
MIDIbox Library
