Hi,

Yes i have modified the LCD driver.

Id=7 "custom LCD", only for adjust contrast @ startup.

It's a Samsung VFD, 4/8bits connection, model 20T202DA1E.

ith all features needed.The only difference is that contrast is digitally controlled.

Find on net @24€.

For the color filter, I used "Lee Filters", after a little test with sampler.

I' ve finally choose number 085 "Deeper Blue":

lee filer number 085

You can find if in professional audiovisual shop.

Or for a little stamp i can send it, a letter format is enough, and i bought 1 meter...

`

Regards.

Share this comment


Link to comment
Share on other sites

Oh and...

Connection! 14 pins cause no led, only 5V supply 150mA typ. 220mA max. (no pots).
