grizz Posted February 10, 2015 Report Share Posted February 10, 2015 Hey everyone, Does somebody have an illustrator file for the MB808 frontpanel? Some friends have a real nice big CNC machine so I can finally pull off the tape labels and get my MB808 a properly etched front panel!! Cheers, Alex Quote Link to comment Share on other sites More sharing options...
Navicat Posted February 11, 2015 Report Share Posted February 11, 2015 There are 3 revisions of the MB808.. DIY i think is the best.. I think our stuff makes us more happy :) Quote Link to comment Share on other sites More sharing options...
Antix Posted February 11, 2015 Report Share Posted February 11, 2015 I need it too please It will be the same for me without sequencer ( a 3U rack only for pots and switches ) Illustrator or FPD or corel or DXF Many thanks for any help Antonio Quote Link to comment Share on other sites More sharing options...
Altitude Posted February 12, 2015 Report Share Posted February 12, 2015 I have the one for rev1-3 Quote Link to comment Share on other sites More sharing options...
grizz Posted February 12, 2015 Author Report Share Posted February 12, 2015 I have the one for rev1-3 Would you mind emailing it to me? apartmentfoxatgmaildotcom Cheers! Alex Quote Link to comment Share on other sites More sharing options...
Navicat Posted February 13, 2015 Report Share Posted February 13, 2015 I think since Midibox is opensource we must share files in public and not in personal messages. Here is your request. MB-808 Front panel for rev 1 and 2 : http://www66.zippyshare.com/v/DCsLyfpD/file.html Regards Tilemachos Quote Link to comment Share on other sites More sharing options...
zephyrin Posted February 25, 2015 Report Share Posted February 25, 2015 Hi antix i have build this rack if you want the fpd file let me known... Quote Link to comment Share on other sites More sharing options...
Navicat Posted February 25, 2015 Report Share Posted February 25, 2015 (edited) Hmm that seems stolen from the TR-8060... I have something similar too this and i made it in SolidWorks 3D and also a nice faceplate. Best Regards, Tilemachos Edited February 25, 2015 by Navicat Quote Link to comment Share on other sites More sharing options...
thumper Posted September 14, 2015 Report Share Posted September 14, 2015 I think since Midibox is opensource we must share files in public and not in personal messages. Here is your request. MB-808 Front panel for rev 1 and 2 : http://www66.zippyshare.com/v/DCsLyfpD/file.html Regards TilemachosHey mate any chance of re-upping this front panel. The link is down and I can't find this anywhere else. Cheers! Quote Link to comment Share on other sites More sharing options...
Altitude Posted September 22, 2015 Report Share Posted September 22, 2015 totally forgot about this thread, sorry. My case file and graphics files are attached. The two illustrator files differ with the holes for the screws to attach the PCB to the front panel. I recommend using the one WITHOUT those holes, its better to countersink the screws and cover them with the sticker. You can mess up the sticker if you screw down on top of it MB808.rar Quote Link to comment Share on other sites More sharing options...
thumper Posted September 22, 2015 Report Share Posted September 22, 2015 Thanks for the file and the info! Good stuff :) Quote Link to comment Share on other sites More sharing options...
